Slack

This node.js example connector allows you to make your Teneo bot available on Slack. The connector acts as middleware between Slack and Teneo and uses the Slack Events API to receive messages from Slack. This guide will take you through the steps of creating a new Slack app and deploying the connector to respond to events sent by Slack.

You can find the source code of this connector on Github.

Prerequisites

Https

The Slack Events API requires that the connector is available via https. On this page we will be using Heroku to host this connector, for which a (free) Heroku account is needed. You can however also manually install the connector on a location of your choice, see Running the connector locally.

Teneo Engine

Your bot needs to be published and you need to know the engine url.

Slack account

You will need a Slack account with permission to add apps to your workspace.

Setup instructions

Create a Slack app

Create a new Slack app here: https://api.slack.com/apps. Give it a name and add it to the appropriate workspace.
On the page that appears, scroll to the bottom of the screen and copy the Signing Secret. You will need it later when you deploy the connector.

Add Bot Token Scopes

In the left navigation menu under 'Features' choose 'OAuth & Permissions'. Scroll down until you see 'Scopes'. Under 'Bot Token Scopes' click the 'Add an OAuth Scope' button. In the field that appears type chat:write

Install App to Workspace

Still on the 'OAuth & Permissions', scroll back to the top and click the 'Install App to Workspace' button and authorize. Copy the 'Bot User OAuth Access Token', you will need it in the next step when you deploy the connector.

Deploy the connector

Click the button below to deploy the connector to Heroku:

Give the app a name (lowercase, no spaces)
In the 'Config Vars' section, add the following:
- SLACK_SIGNING_SECRET: The 'Signing Secret' you copied when you created the Slack app.
- SLACK_BOT_USER_OAUTH_ACCESS_TOKEN: The 'Bot User OAuth Access Token' you copied when you installed the app to your workspace.
- TENEO_ENGINE_URL: The engine url.
Click 'Deploy app'.

When Heroku has finished deploying, click 'View app' and copy the url of your Heroku app, you will need it in the next step.

If you prefer to run your bot locally, see Running the connector locally.

Subscribe to events

Go back to your app on Slack. Then:

In the left navigation menu under 'Features' choose 'Event Subscriptions'.
Turn on Enable Events.
Enter the following URL in the Request URL field: https://[yourherokuappname].herokuapp.com/slack/events (replace [yourherokuappname] with the name of your app on Heroku).

Note that the url ends with /slack/events, and that the connector is already running locally, or on Heroku, to avoid a 'Challenge parameter' error.

Under 'Subscribe to Bot Events', subscribe to the following event: message.im
Save changes. Reinstall the app, if recommended by the dashboard

That's it! Your bot should now be available in Slack and responding to messages that are sent to it. 🕺

Test your bot

Open the Slack app or visit slack.com in your browser and go to the workspace in which you added your bot.

In the navigaton on the left, click on the plus sign next to Direct Messages.
Search for the name of your bot, select it and click 'Go'.
Let's talk.

To add message attachments, this connector looks for an output parameter slack in the engine response. The value of that parameter is assumed to contain the attachement JSON as defined by Slack.

If we look at Slack's JSON specification of attachments, to attach an image the value of the slack output parameter would need to look like this:

json

1{
2    "fallback": "Image description as fallback",
3    "image_url": "https://url.to/an/image.png"
4}
5

Note: although it is possible to add multiple attachments to a Slack message, this connector assumes the output parameter contains just the JSON for a single attachment.

For more details on how to populate output parameters in Teneo, please see: How to populate output parameters in the Build your bot section.

Running the connector locally

If you prefer to manually install this connector or run it locally so you can extend it, proceed as follows:

Download the latest release of the connector from Github
Install dependencies by running npm install in the folder where you unzipped the connector.
Make sure your connector is available via https. When running locally you can for example use ngrok: ngrok.com. The connector runs on port 3000 by default. ngrok http 3000
Start the connector with the following command (replacing the environment variables with the appropriate values): SLACK_SIGNING_SECRET=<your_slack_signing_secret> SLACK_BOT_USER_OAUTH_ACCESS_TOKEN=<your_slack_bot_oauth_token> TENEO_ENGINE_URL=<your_engine_url> node server.js
